Fuses Usage
DRIV DR
SWTCH
Driver Door Switch
TELE
SWTCH/MSM
Telescope Switch, Memory Seat
Module
IGN SWTCH/
INTR SNSR
Ignition Switch, Intrusion Sensor
BCK/UP LAMP Reverse Lamps
REVERSE
LAMPS
Reverse Lamps
Blank Not Used
STOP LAMP Stop Lamp
BTSI SOL/STR
WHL LCK
Brake Transmission Shift Interlock,
Steering Wheel Column Lock
BLANK Not Used
RDO/S-BAND/
VICS
Radio, S-Band, VICS
REAR
FOG/ALDL/
TOP SWTCH
Rear Fog Lamp, Assembly Line
Diagnostic Link Connector,
Convertible Top Switch
GM LAN
RUN/CRNK
GM LAN Devices
Fuses Usage
ISRVM/HVAC
Electric Inside Rearview Mirror,
Heating Ventilation, Air Conditioning
CRUISE
SWTCH
Cruise Control Switch
TONNEAU
RELSE
Tonneau Release
RUN CRNK Run/Crank Relay
HTD SEAT/
WPR RLY
Heated Seat, Wiper Relays
ECM Engine Control Module
SDM/AOS
SWTCH
AIRBAG
Sensing and Diagnostic Module,
Automatic Occupant Sensing
Module, Airbag
CLSTR/HUD Cluster, Heads-Up Display
HVAC/PWR
SND
Heating, Ventilation/Air Conditioning,
Power Sounder
EXH MDL
Exhaust Module (Z06); Spare
(Coupe and Convertible)
DR LCK Door Locks
CTSY/LAMP Courtesy Lamp
SWC DM Steering Wheel Dimming
422
