Vehicle Care 253
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Number Usage
1 DLIS
2 Data Link
Connector
3 Airbag
4 Liftgate
5 Spare
6 Body Control
Module 8
7 Body Control
Module 7
8 Body Control
Module 6
9 Body Control
Module 5
10 Body Control
Module 4
11 Body Control
Module 3
12 Body Control
Module 2
13 Body Control
Module 1
Number Usage
14 Instrument Cluster
15 OnStar
16 Rear Parking
Assist
17 Rain Sensing
Wiper
18 Audio
19 Trailer
20 VLBS/FCA/LDW
21 CHEVYSTAR
22 Heating,
Ventilation, Air
Conditioning
23 HDLP ALC
24 Clutch
25 Instrument Cluster/
Automatic
Occupant Sensing
26 Airbag Run/Crank
27 Run Relay
28 Liftgate Release
