Chevrolet sonic 2016 User Manual

Chevrolet Sonic Owner Manual (GMNA-Localizing-U.S/Canada-9085902) -
2016 - CRC - 5/27/15
252 Vehicle Care
Mini Fuses Usage
32 Transmission
Control Module
33 Horn
34 Front Fog Lamps
35 Left High Beam
36 Right High Beam
J-Case
Fuses
Usage
1 Front Wiper
2 Antilock Brake
System Pump
3 Blower
4 Run/Crank IEC
6 Cooling Fan K4
7 Cooling Fan K5
8 SAI Pump*
9 EVP
10 Start
Micro
Relays
Usage
RLY 1 Front Wiper
Control
RLY 3 Front Wiper Speed
HC-Micro
Relays
Usage
RLY 12 Start
U-Micro
Relays
Usage
RLY 6 Not Used/SAI
Valve*
RLY 13 Air Conditioning
Compressor Clutch
RLY 14 High-Beam
Headlamps
Mini Relays Usage
RLY 4 Rear Defogger
RLY 5 Run/Crank
RLY 9 SAI Pump*
RLY 10 Cooling Fan K3
Mini Relays Usage
RLY 11 P/T
RLY 15 Cooling Fan K1
* = If equipped
Instrument Panel Fuse
Block
The instrument panel fuse block is
on the underside of the driver side
instrument panel.
