Chicago Pneumatic CP7300C - Page 3

Model
Stall
Torque
Free
Speed
Power
Chuck
Capacity
Dimension
LxWxH
Weight
Air Consump
-
tion
Air
Inlet
Inner
Hose
Dia.
Sound
Pressure
LpA
Sound
Power
LwA
Vibrations
ahd K
L
W
H
1 2 3 4 5 6 7 8 9 10 11 12
[ft.lb]
[Nm]
[rpm]
[hp]
[kW]
[inch]
[mm]
[inch]
[mm]
[lb]
[Kg]
[SCFM]
[Nl/s]
[inch]
[inch]
[mm]
[dB(A)] [dB(A)]
[m/s²] [m/s²]
CP7300C
1.9
2,6
3300
0.3
0,23
1/4
6
6.7 x 1.5 x 5.7
170 x 38 x 145
1.4
0,64
21.2
10
1/4“ NPT
3/8"
10
85 86
<2,5 /
CP7300RC
1.9
2,6
2800
0.3
0,23
1/4
6
7.3 x 1.5 x 5.7
170 x 38 x 145
1.5
0,67
21.2
10
1/4" NPT
3/8"
10
85 86
<2,5 /
CP7300RQCC
1.9
2,6
2800
0.3
0,23
1/4
6
7.5 x 1.5 x 5.7
170 x 38 x 146
1.5
0,69
21.2
10
1/4“ NPT
3/8"
10
85 86
<2,5 /
1
2
Reversible
Non- Reversible
Non- Reversible
Reversible
1
3
Assembly
Disassembly
