Instruction manual
1310 3012 13 11
Once the post is in vertical position, adjust the post height by
handling the leveler clock wise until the post is in contact with
the ground.
4. Set the front legs by first extending the leg tubing as described
below.
Pull the horizontal safety pin in order to be able to unfold the
post arm and lower the post.
Pull the post safety pin in order to be able to turn and lower the
post and return the pin to the safe position.
Once the post is in vertical position, adjust the post height by
handling the leveler clock wise until the post is in contact with
the ground.
5. Level the light tower by adjusting each jacking leg and using the
bubble level located on the tong
