ORDERING SPARE PARTS
CPLT
ORDERING SPARE PARTS
Always quote the part number, the designation and the quantity of the
parts required, as well as the type and the serial number of the machine.
EXPLANATION OF THE COLUMNS
REF : REFERENCE CODE
Establishes the connection between a part in the list and a part in the illus-
tration.
"–" means that the part is not shown in the illustration.
PART NU MBER
If no part number is given, the part cannot be obtained as a spare part.
Parts marked with a dot are part of the assembly listed right above them.
DESIGNATION
Usually this is the name of the part. For standard parts, in addition to the
name, a number of characteristics are given.
QTY : QUANTITY
Indicates the quantity of the part concerned. "AR" stands for "As
Required".
