40 1310 3012 13
YANMAR BUILD KIT
10 1310 0810 61 REAR LEG 2
20 1310 0810 62 FRONT LEG 2
30 1310 0810 63 TUBE RADIATOR SPACER MTG 2
40 1310 0810 64 TUBE AIR CLEANER BRACKET 1
50 1310 0810 65 PLATE AIR CLEANER MOUNTING 1
60 1310 0810 66 BRACKET RADIATOR MTG 1
70 1310 0810 67 BRACKET MUFFLER SUPPORT BLOCK 1
80 1310 0810 68 BRACKET MUFFLER SUPPORT 1
90 1310 0810 69 ISOLATOR ENGINE MOUNT 4
100 1310 0810 70 A/C KIT FOR YANMAR ENGINE 1
110 1310 0810 71 MUFFLER KIT FOR YANMAR 1
120 1310 0810 72 SEAL AR
130 1310 0810 73 SEAL AR
REF PART NUMBER DESIGNATION QTY REF PART NUMBER DESIGNATION QTY
1310 0810 06/01
