Chicago Pneumatic Compressors
62 305 799 65
The CP COMPRESSOR should never be operated beyond its capabilities
or in any way which does not comply with the instructions contained
in this operating and maintenance guide.
Chicago Pneumatic Compressors will decline any responsibility
if these instructions are not respected.
This equipment has been factory tested and satisfies normal
operating conditions: they must not be exceeded
as this would place the machine under abnormal stress and effort.
INSTALLATION INSTRUCTIONS
For the guarantee to be valid, the unit must be assembled in covered
premises with temperatures not exceeding :
Mini: + 36 °F (frost free)
Maxi: + 104 °F
You must also have:
3,33 ft space around the compressor
-
low ventilation (fresh air) proportionate to the ventilation flow necessary for the machine and protected
from any infiltration of humidity (splashes of water during bad weather) and all pollution
-
top insulation or extraction to ensure reversal of the flow of warm air and evacuation of the heat to
outside the equipment room
-
a link from the condensation water evacuation pipe to the drain discharger.
-
In case of dusty ambient environment, a pre-filtration is made by micro-filter on the air inlet of the room used for cooling and
perhaps a special filter on the compressor air inlet.
TECHNICAL CHARACTERISTICS
STANDARD MACHINES
CPF 175 200
Nominal pressure at full capacity PSI 100 125 150 175 100 125 150 175
Real flow*
(as per ISO 1217 ed 1996) cfm 865 820 744 603 1011 966 876 729
Motor power hp 175 200
Ø Pressure outlet (F) Inch 3" PN16 DN80 3" PN16 DN80
Oil receiver capacity gal 23,7 23,7
Residual quantity of oil ppm 3 3
Noise level at 3,3 ftdB(A) 73 74
(according to PNEUROP PN 8 NT C2)
* Suction pressure : 14.5 PSI absolute - Relative humidity : 0 % - Ambient temperature : 68 °F
- Effective delivery pressure : 102 PSI, 109 PSI, 138 PSI or 181 PSI (effective)
Dimensions (in) L x w x h 104,9x58,6x76,3 111,8x63,3x78,4
Approximate weight (Air) lbs 5655 6239
