Chicago Pneumatic Compressors
62 305 258 65
01/2008
Page 3
CPVS Model 40 50 60 75
Motor power (hp) 40 50 60 75
Main Voltage 460 Volt / 3 / 60 Hz
Nominal current (A) 69 81 89 125
Power supply cable AWG 4 AWG 3 AWG 1 AWG 0
Fuse protection (Type RK5) 80 100 125 150
Connection of the electric plate to an external control box
• Install an RC filter on the KM1 coil.
• Install an RC filter on the KM2 coil.
• All connections between external parts and the compressor must be carried out using a shielded cable, which must be grounded at one of its
ends.
WARNING: the operation connection cables between the different elements must never follow the same path as the existing power
cords. A separate installation from the power cords must be carried out.
• Install an RC filter on all the relay coils of the external operation units.
