Chicco CORSO FLEX - Connect 5-Point Safety Harness

18 19
How to Use Modular Seat
11. This stroller has a 5-point
safety harness. The Shoulder
Strap Connector is designed to
break away from the Waist Clip
when not secured in the Crotch
Strap Buckle.
Make sure the Shoulder Strap
Connector is in the correct
position, as shown. Slide the
Shoulder Strap Connector onto
the Waist Strap Clip and repeat
for the other side. Then slide both
Waist Clips into the Crotch Strap
Buckle, as shown. Pull on both
sides to make sure the Clips are
secured to the Buckle.
11
How to Use Modular Seat
10B
10B. To adjust the Shoulder
Harness to another height
position, locate the D-ring on the
back of the seat as shown. Release
the hook and loop material at the
top of the seat back to expose
the seat board. Slide the D-ring
through opening on the seat back.
Then pull through the opening on
the seat pad. Re-insert the D-ring
into the correct height position,
and repeat for the other side.
Always use the same height
position for both straps.
Depending on Shoulder Harness
height position, D-ring may be
located below visible opening in
seat back.
Seat Front
