How to Use Modular Seat
WARNING
This stroller features three harness positions. Always use a harness position
located ABOVE the child's shoulder line. If multiple harness positions are
above the child's shoulder line, use the one closest to it.
10A. The Shoulder Straps can be
adjusted to 3 height positions as
shown.
10A
3
2
1
How to Use Modular Seat
9B. Open the Seat Frame (E). Line
up and insert the attachment hubs
on both sides of the Seat Frame
into the lower attachment slots
on the Stroller Frame, as shown
(9C). Pull up on the Seat Frame to
make sure it is securely attached
to the Stroller Frame.
9B
“CLICK!”
9C
To Next Page
