44
30A. Undo the hook and loop and
locate the Shoulder Strap D-rings.
Push the Shoulder Strap D-rings
through the seat back (refer to
Step 17B). Pull the Shoulder Straps
through the front side to remove.
30B. Make sure to push the waste
belt straps through the openings in
the seat fabric, as shown.
30A
How to Remove the Seat Fabric
30B
