Hoist Specication
Lifting capacity WP, WBP, WLP, WLBP models - 130 Kg (20 stone)
WTP, WLTP, WTBP, WLTBP models - 200 Kg (31 stone)
Case construction Injection moulded Flame Retardant ABS
Lifting Range Approximately 1800mm*
No of Lifts per Charge 60** (Battery models)
Battery voltage 24 vdc
Overload cut out <150% maximum load (All models)
Hand control Pneumatic hand control
Track Aluminium extruded track
Low battery indication Audible and visual warning device on hoist (On battery models only)
Clearance dimension Top of track to bottom of carry bar hook at max height is 442mm
*This is adjustable and should be set by the installer to meet the requirements of the user. Typically the carry bar would stop about 300mm from
the oor. Extended tapes are available to accommodate high ceilings
**600mm up and down cycle with average 70kg (11 stone) patient weight.
CE Mark
The Chiltern Invadex Wispa 100Plus Hoist carries the CE mark and complies with the Medical Devices Directive (93/42/EEC) as amended
2007/47/EC
1782mm
maximum lifting range
with standard tape
1922mm
with standard tape
480mm
between pick up points
442mm
minimum
