Applicatin Information
a) The normal operating ambient temperature of the product is - 5 ℃ ~ + 40 ℃;
Note: if it is used within the range of - 35 ℃ ~ + 70 ℃, please consult with the manufacturer.
b) If the altitude exceeds 2,000m, please consult with the manufacturer;
c) Class of pollution: Class 3;
d) Main circuit installation category:Ⅲ
e) Enclosure protection class: IP20.
;
Inspection and Test
01
NXZ Automatic Transfer Switch
Inspection
Determine product technical parameters.
Necessary tools
Cross screwdriver
Straight screwdriver
Outer hexagon
Figure 1 Inspection
2m
M3×12,M3
M4×60,M4
M5×70,M5
×1
×1
×3 ×1
×3
×1 ×1
M8×100,M8
Product model NXZ-125 NXZ-250 NXZ-630 Note
Specification
of mounting
screw and nut
Standard
Flash
barrier
3P
4P
4
8
9
5
6
1
1
2
2
External
signal
terminal
Type
A
Type
B
Wire
Wire holder
Wire holder
mounting
screw
Mounting
screws and
nuts
Optional, for split
type installation of
display module,
indicated when
ordering.
Tabla 1 Standard accessories
