CHMER Wire-Cut EDM Operation Manual W5F
1-1 System Composition
Wire Cut machine is consisted of three major parts：Power Cabinet, Machine Tool, and
Filtration Unit.
1. Power Cabinet
Contains majority of fuses, TFT LCD Display, Power Line, Computer and
Sparking Circuit.
2. Machine Tool
There are two types of Machine Tool: Submerged and Flushing, which differed
from each other by whether equipped with (S) a stainless tank or not (F). For
example, CW 530S, CW 530F.
3. Filtration Unit
For dielectric filtration and de-ionization.
Power Cabinet
Machine Body
Filtration Unit
Filtration Unit
1-1
