Chord Electronics
Mojo 2 | User manual
10
7 Advanced operation
Mojo 2 benefits from a cutting-edge UHD DSP control which provides a number of advanced features,
accessible via the menu button. Pressing the menu button sequentially, cycles through the various
features explained in this section.
7.1 Menu: button colour information
The menu button changes colour as menu options are selected. The chart below provides a guide.
TIP
Lift fingers between menu button presses to see the menu button colour and function selected.
Menu colour Menu mode
Volume range
Brightness adjustment/Crossfeed mode
Bass 20 Hz
Bass 125 Hz shelf
Treble 3 kHz shelf
Treble 20 kHz
Lock control
