3–6 Chris-Craft
Systems
The hatch seal should be maintained on a regular basis by applying a thin layer of silicone sealant to the
seal.
A remote key ring (Figure 3-4) is available to open/close the rumble seat and turn the cockpit lights on and
off. To program the key ring:
1. Access the control unit inside the rumble seat area behind the port closeout and open the cover.
2. Locate the button located next to the LED and press once.
3. Press the upper left button on the key ring twice.
4. Replace the cover on the control unit.
5. Test for proper operation.
Figure 3-4. Lancer 22 Rumble Key Ring
Rumble Seat:
OPEN
Rumble Seat:
CLOSE
Cockpit Lights:
ON
Cockpit Lights:
OFF
