Systems
Chris-Craft 3–13
Fuel Tank
Fuel capacities are approximate measures. Always allow for ade-
quate reserve of fuel when operating the boat.
All Chris-Craft boats have either aluminum or crosslink polyethylene fuel tanks with varying capacities.
Usable fuel will be less than capacity rating and depends upon trim conditions. Good seamanship calls for
an adequate fuel reserve in all boating activities.
The fuel tank fill deck plate is located on the opposite side of the
water fill deck plate. DO NOT put fuel in the water tank or water in the
fuel tank.
The fuel fill deck plate (Figure 3-9) is located on either the starboard or port gunnel of the boat. Actual
location, and physical appearance may vary from model to model, but the cap is clearly labeled.
Figure 3-9. Fuel Tank Fill Deck Plate
