Digital Power Meter 66200 Series User’s Manual
[ CALCulate : ] COMParator : TIME 66201 | 66202
Description: Programming “COMP:TIME” decides the dwelling time of comparison
function. The unit of Setting Parameter is second.
Setting Syntax:
COMParator:TIME<space><NR1><PMT>
Setting Parameters: <NR1>, 0 ~ 9999
Query Syntax: COMParator:TIME?<PMT>
Response Parameters: <NR1>, 0 ~ 9999
Header on: :COMPARATOR:TIME<space><NR1><RMT>
Header off: <NR1><RMT>
Example: none
[ CALCulate : ] COMParator : RESult? 66201 | 66202
Description: This query command returns the result of comparison. The return value is
PASS/FAIL/NONE.
Setting Syntax:
none
Setting Parameters: none
Query Syntax: COMParator:RESult?<PMT>
Response Parameters: <CRD>, NONE∣PASS∣FAIL
Header on: :COMPARATOR:RESULT<space><CRD><RMT>
Header off: <CRD><RMT>
Example: none
[ CALCulate : ] COMParator : FAIL? 66201 | 66202
Description: This query command returns the measured items which are out of programmed
boundaries. The return strings of measured item are listed in
Response
Parameters.
Setting Syntax: none
Setting Parameters: none
Query Syntax: COMParator:FAIL?<PMT>
Response Parameters: <CRD>, NONE, V, VPK+, VPK-, THDV, I, IPK+, IPK-, IS, CFI,
THDI
, W, PF, VA, VAR, ENEG, FREQ
Header on: :COMPARATOR:FAIL<space><CRD>,<CRD>,...<RMT>
Header off: <CRD>,<CRD>,...<RMT>
Separator 0: <CRD>,<CRD>,...<RMT>
Separator 1: <CRD>;<CRD>;...<RMT>
Example: none
[ CALCulate : ] COMParator : ITEM 66201 | 66202
Description: This command is used to select measured items as comparison items in GONG
mode.
Setting Syntax: COMParator:ITEM<space><CRD>,<CRD>,<CRD>,…<PMT>
Setting Parameters: <CRD>,
66201: V, VPK+, VPK-, I, IPK+, IPK-, CFI, W, PF, VA, VAR, FREQ
66202: V, VPK+, VPK-, THDV, I, IPK+, IPK-, IS, CFI, THDI, W, PF, VA,
VAR, ENEG, FREQ
Query Syntax: COMParator:ITEM?<PMT>
Respons
e Parameters:
<CRD> NONE
V
VPK+
VPK
-
THDV
I
IPK+
IPK
-
IS
CFI
5-26
