Chroma 66202 - CALCULATE Sub-system Commands

Using Remote Control
5-25
[ SOURce : ] WAVeform : CAPture? 66202
Description: This query performs the acquisition of new waveform once and returns the
status of this action.
Setting Syntax: none
Setting Parameters: none
Query Syntax: WAVeform:CAPture?<PMT>
Response Parameters: <CRD>, OK∣FAIL
Header on: :WAVEFORM:CAPTURE<space><CRD><RMT>
Header off: <CRD><RMT>
Example: none
[ SOURce : ] WAVeform : DATA? 66202
Description: This query returns voltage or current waveform data from the Power Meter in
binary format. The waveform either voltage or current are consist of 8192 points
in format of 32bits float point.
Setting Syntax: none
Setting Parameters: none
Query Syntax: WAVeform:DATA?<space><CRD><PMT>
Query Parameters: <CRD>, V∣I
Response Parameters: <DLABRD>, #6032768<byte1><byte2><byte3>…<byte32768>
Header on: :WAVEFORM:DATA<space><DLABRD><RMT>
Header off: <DLABRD><RMT>
Example: none
CALCULATE Sub-system
[ CALCulate : ] COMParator 66201 | 66202
Description: Users can configure upper and lower boundary of measured items. 662xx will
check measured items according to the boundaries. Once any item exceeds the
boundaries, the item will be recorded. The command is used to turn on/off the
comparison function.
Setting Syntax: COMParator<space><CRD><PMT>
Setting Parameters: <CRD>, ON∣OFF
Query Syntax: COMParator?<PMT>
Response Parameters: <CRD>, ON∣OFF
Header on: :COMPARATOR<space><CRD><RMT>
Header off: <CRD><RMT>
Example: none
#6032768<byte1><byte2><byte3><byte4><byte5><byte6><byte7><byte8>...
P
oint #1
P
oint #2
L
ow byte ―――→ High byte
