14 Chromalox 2104 Technical Manual
Figure 2.16
Current/Voltage
Output Jumper Positions
Top
Controller Rear View
Output #1*
Output #2
4-20mA 1-5 Vdc
4-20mA 1-5 Vdc
*All controllers with Analog Output (output codes AR, AT) for
output #1 use same 4-20mA/1-5 Vdc jumper positions as shown here.
Output Module
