18
Heating Cable Components
Connection Kits
Table 5 – U Series Connection Kits Overview
Catalog Number Description
Installation
Manual
UPC
Power Connection
Box
NEMA 4X rated junction box designed to connect
cables to customer supplied power wiring. This
kit provides water-resistant cable entry for one
cable, enclosure support, terminal block, and a
water-resistant corrosion-resistant wiring enclo-
sure with a 3/4” opening to accept a conduit hub
(CCH-2 or equal)
PJ495
UMC
Multiple Entry Power
Connection Box
NEMA 4X rated junction box designed to connect
two or three cables. This kit provides water-
resistant cable entry, enclosure support, terminal
block, and a water-resistant, corrosion-resistant
wiring enclosure. In addition to splicing or teeing
cables, this model can be used to provide power
connection to up to three cables from one con-
nection kit.
PJ497
UES
Above Insulation End
Seal Kit
NEMA 4X rated end seal designed to terminate
cables. This kit provides water-resistant cable
entry for one cable. It has a corrosion-resistant
pipe support that brings the cable end outside of
the insulation for easy access.
PJ496
UESL
End Seal Signal
Light Kit
NEMA 4X rated end seal designed to seal one
cable and indicate power on with universal volt-
age 120-277 LED indicator light. This model
provides water-resistant cable entry, enclosure
support, terminal block, and corrosion-resistant
wiring enclosure. Available in red and green.
PJ448
USL
Power/End Seal
Signal Light Kit
NEMA 4X rated end seal designed to power or
seal one cable and indicate power on with uni-
versal voltage 120-277 LED indicator light. This
model provides water-resistant cable entry,
enclosure support, terminal block, and corro-
sion-resistant wiring enclosure.
PJ937
SSK
Single Entry
Sealing Kit
This kit provides water-resistant cable entry for
one cable. It has a corrosion-resistant pipe sup-
port that brings the cable end outside of the
insulation for easy connection to power.
PJ498
