Page | 89
SAVE SETTINGS [CONTINUED]
Text Overlay
(H.264/TIFF)
When enabled, the timestamp overlay will be shown on top of the image in
Playback mode, videos saved as H.264 MPEG-4, and images saved as TIFF.
Information about each frame’s position within the recording will be overlaid
across the bottom left corner of each frame of encoded video or TIFF image.
Selects the storage device for saved video. The list automatically refreshes and
switches to the most recently attached device. Please note that it may take
several seconds for a newly connected storage device to appear in the list.
Specifying a Folder Path will make the camera save the video into that folder
once Save is pressed. If saving in DNG, TIFF, or TIFF RAW, an image for each
frame will be saved into a sub-folder within the folder specified.
Sets the filename for saved video on the device selected in Save Location. If this
field is left blank, the files will be named vid_YYYY-MM-DD_HH-MM-SS.mp4
according to the current date and time.
Finish any outstanding writes to selected storage device. When this has
completed, the storage device can be unplugged from the camera without the
risk of lost data. This action is similar to the Eject or Safely Remove action on a
PC.
Closes the Save Settings dialog. Settings are applied automatically upon being
set.
NOTE: In the rare event that a save operation is unsuccessful and it is critical to recover high-
speed footage that was captured, an internal tool can be used to attempt the recovery and saving
of frames in the CinemaDNG format. DO NOT power off the camera if a recovery attempt is to be
made, as rebooting the camera will clear the acquisition memory in which the last capture of high-
speed footage resides. Please contact support@krontech.ca for more information.
