Cavity Cartridge Fuse Blade Fuse Description
F09 – – Not Used
F10 – 20 Amp Yellow Power Transfer Unit (PTU) –
If Equipped
F11 – – Not Used
F12 – 20 Amp Yellow Brake Vacuum Pump – If
Equipped
F13 – 10 Amp Red Engine Control Module
(ECM)/VSM (Engine Stop/
Start Only)
F14 – 10 Amp Red Drivetrain Control Module
(DTCM)/Power Transfer
Unit (PTU) – If Equipped/
RDM/Brake System Module
(BSM)/Brake Pedal Switch/
EPB (Electric Park Brake)
F15 – – Not Used
630 MAINTAINING YOUR VEHICLE
