Cavity Cartridge Fuse Blade Fuse Description
F16 – 20 Amp Yellow Ignition Coil
F17 – – Not Used
F18 – – Not Used
F19 40 Amp Green – Starter Solenoid
F20 – 10 Amp Red A/C Compressor Clutch
F21 – – Not Used
F22 – 5 Amp Tan Radiator Fan Enable
F23 – 70 Amp Tan Body Controller Module
(BCM) – Feed 2
F23 – 50 Amp Red Voltage Stability Module
(VSM) #2 – If Equipped With
Engine Stop/Start Option
F24 – – Not Used
7
MAINTAINING YOUR VEHICLE 631
