TEST ACTION APPLICABILITY
3 Turn the ignition off.
Disconnect the PCM harness connector.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Measure the resistance of the PCI Bus circuit between the DLC and the PCM
connector.
Is the resistance below 5.0 ohms?
All
Yes → Replace and program the Powertrain Control Module in accor-
dance with the Service Information.
Perform BODY VERIFICATION TEST - VER 1.
No → Repair the PCI Bus circuit for an open.
Perform BODY VERIFICATION TEST - VER 1.
41
BRAKES (CAB)
PCM MESSAGES NOT RECEIVED — Continued
