Chrysler Pacifica 2004 - Fuses (Ipm)

FUSES (IPM)
FUSE
NO.
AMPS FUSED CIRCUIT FUNCTION
1 40A A107 12TN/RD FUSED B(+)
2- - -
3 30A INTERNAL FUSED B(+) (I.O.D.)
4 40A A101 12VT/RD FUSED B(+)
5 40A INTERNAL FUSED B(+)
6 30A INTERNAL FUSED B(+)
7 40A INTERNAL FUSED B(+)
8 40A A110 12DG/RD FUSED B(+)
9 40A A130 12VT/RD (POWER SUNROOF) FUSED B(+)
10 30A A701 14BR/RD (EARLY BUILD) FUSED B(+)
10 30A A100 16RD/VT (TRAILER TOW LATE BUILD) FUSED B(+)
11 40A A115 12YL/RD (POWER LIFTGATE) FUSED B(+)
12 - - -
13 40A A112 12OR/RD FUSED B(+)
14 - - -
15 40A A111 12DG/RD FUSED B(+)
24 20A F307 16LB/PK FUSED ACCESSORY RELAY OUTPUT
25 15A F316 20PK/OR FUSED ACCESSORY RELAY OUTPUT
26 20A F306 16DB/PK FUSED ACCESSORY RELAY OUTPUT
27 - - -
28 25A INTERNAL FUSED B(+)
29 20A A108 18LG/RD FUSED B(+)
30 10A A106 20LB/RD FUSED B(+)
31 20A A701 18BR/RD (LATE BUILD) FUSED B(+)
31 20A A100 18RD/VT (TRAILER TOW EARLY BUILD) FUSED B(+)
34 10A C51 18LB/BR FUSED REAR BOOSTER FAN RELAY OUTPUT
35 - - -
36 20A INTERNAL FUSED B(+)
37 25A INTERNAL FUSED B(+)
38 20A INTERNAL FUSED B(+)
39 20A A109 18OR/RD FUSED B(+)
40 40A F515 12PK/LB FUSED DOOR NODE RELAY OUTPUT
41 40A F516 12PK FUSED DOOR NODE RELAY OUTPUT
42 40A C7 12DB FUSED FRONT BLOWER MOTOR RELAY OUTPUT
44 25A F525 16TN/PK (MIDDLE ROW HEATED SEATS) FUSED RUN RELAY OUTPUT
45 10A INTERNAL FUSED RUN RELAY OUTPUT
46 20A A214 18RD/LB FUSED B(+)
47 20A A215 18RD/LG FUSED B(+)
48 15A A114 20GY/RD FUSED B(+)
49 25A A116 16YL/RD FUSED B(+)
50 15A A118 20RD/OR FUSED B(+)
C
O
N
N
E
C
T
O
R
P
I
N
O
U
T
S
52
CONNECTOR PINOUTS
