Chubb PEFS F3 User Manual

Maintenance Manual 27
PEFS F3 Maintenance Manual, Version 1.2, Feb 2018
© Copyright 2017 Chubb Fire & Security Pty Ltd
SPARE PARTS
Cylinder Assemblies & Brackets
Cylinders Assembles
Figure 6
Cylinder Assembly Details:
Part Number
109508
109510
109511
109512
111045
Description
C23 Cylinder
C30 Cylinder
C45 Cylinder
C65 Cylinder
C106 Cylinder
Water Capacity
23 lt.
30 lt.
45 lt.
65 lt.
106 lt.
Height (mm)
726
512
572
772
1188
Height with Valve
960
740
820
1020
1440
Diameter (mm)
216
318
360
360
360
Design
Registration
V1061-84 /
V1301719
V881-82 /
V1301721
V376-84 /
V1301718
V376-84 /
V1301718
V376-84 /
V1301718
Test Pressure
6 MPa /
3.3 MPa
3.3 MPa /
3.3 MPa
3.6 MPa /
3.3 MPa
3.6 MPa /
3.3 MPa
3.6 MPa /
3.3 MPa
Total Fill
18 lt.
24 lt.
35 lt.
50 lt.
85 lt.
Water quantity
16 lt.
21.5 lt.
31 lt.
44 lt.
75 lt.
Foam quantity
2 lt.
2.5 lt.
4 lt.
6 lt.
10 lt.
Pressure
@ 21
o
C
1700 kPa
1700 kPa
1700 kPa
1700 kPa
1700 kPa
Empty Mass
(incl Valve Assy)
10.9 kg
12.1 kg
13.5 kg
17.6 kg
24.3 kg
Gross Mass
(incl Fill)
28.9 kg
36.1 kg
48.5 kg
67.6 kg
109.3 kg
Total Mass
(incl Fill &
Bracket)
38.9 kg
45.5 kg
65.5 kg
84.6 kg
134 kg
Table 6 - PEFS F3 cylinder specifications
Item
Part Number
Description
1
112255
Burst Disk
2
23100
Filler Plug Assembly
3
90127
Filler Port O-Ring
4
60328
60329
60330
Label – Blue Identification Band C30 & C45 Cylinders
Label – Blue Identification Band C23 & C65 Cylinders
Label – Blue Identification Band C106 Cylinder
5
66139
Label – Main PEFS F3 Cylinder Label
Table 7 – Cylinder Assembly Parts
1
4
2 & 3
