Exploded view & dismantling sequence of parts
- 24 -
2. Exploded view schedule of outdoor unit of FR(D)95, FR(D)125/S, FR(D)100-B, FR95-C &
FR125-C/S
No. Description Remark
1 Top cover assembly
2 Air intake mesh assembly
4 Right panel assembly
5 Condenser
6 Capillary assembly
7 T-pipe assembly
8 Valve Dg8
9 Motor support
10 Flat washer 5
11 Spring washer 5
12 Motor
13 Nut M5
14 Axial flow fan
15 Front panel assembly
16 Handle
17 Electric assembly
18 Baffle plate assembly
19 Air exhaust pipe
20 Reversing valve assembly
21 Pipe (2)
22 Pipe (1)
23 Air suction pipe
24 Compressor junction box cover
25
Dg13(FR(D)95, FR95-C, FR(D)100-B), Dg16 (FR(D)125/S,
FR125-C/S)
26 Compressor
27 Damper ring
28 Chassis assembly
