List of main parts & wear parts
- 61 -
4. List of main parts & wear parts of FR95-C and FR125/S-C
Size/Model
Symbol Description
FR95-C FR125-C/S
PCB1 Main control board ------ ------
PCB2 Wire controller ------ ------
PCB3 Remote controller ------ ------
RT1 Temperature sensor 3324 3324
RT2 Temperature sensor 3324 3324
RT3 Temperature sensor 3324 3324
C1 Capacitor
CBB61A 5μF/AC 450V CBB61A 8μF/AC 450V
C2 Capacitor
CBB611A 6μF/AC 450V CBB611A 8μF/AC 450V
C3 Capacitor
CBB65A 60μF/AC 450V
------
C4 Capacitor
CBB65A-1K 50μF/AC450V
------
Communication line RF10AW/FG.000.01 RF10AW/FG.000.01
OD pipe temp probe line RF10AW/FG.000.02 RF10AW/FG.000.02
M1 Outdoor fan motor YDK
3
120/45-6 YDK
2
120/45-6
M2 Compressor ZR47K3-PFJ ZR61KC-TFD
M3 Indoor fan motor YSK139/35-6 YSK139/35-4
T Transformer Z371 Z371
FU Fuse 10A 10A
YV Reversing solenoid valve STF-0408 STF-0408
KM AC contactor B30-10-10(220V) or 3TF3100
EB16-30-00(230V)
(220V)3TF3100
Valve Dg8 Dg8
Valve Dg13 Dg16
Axial flow fan RF10W/FG.000.04WX RF10W/FG.000.04WX
Impeller FR95-CN.062.00 FR95-CN.062.00
