MODES OF OPERATION
aps
ap
movement
Deectors
Filter
Heat
Fan
Exchanger
“ SWING ” CONTROL OF THE AIR FLOW
A IR
S W ING
The air outlet ow is uniformly dist-
ributed in the room.
It is possible to position the direction
of the air for optimal distribution.
The SWING button activates the “FLAP” and the air ow
is directed alternatively from up to down .
In order to guarantee an even diusion of the air in the
room.
In cooling mode , orient the aps in horizontal
direction;
In heating mode, orient the aps downward as
the warm air always tends to rise upward.
The deectors are positioned manually and placed un-
der the aps .They allow to direct the air ow righ or
left.
CAUTION!
Never position Flaps manually, the delicate mech-
anism activating them could be seriously damaged!
DANGER!
Never insert your hand or objects in the air outlet of
the units!These units contains a fan that turns at high
speed.
This adjustment must be done with the unit
switched o.
AIR
SWING
OFF
ON
C
AUTOQUIET
POWE R FUL
hr
DELAY
TIME R
HEALTHY
AIR
SWING
FAN
SPE ED
9
The conditioner is designed to create the comfortable
climatic conditions for the people in the room.
The direction of the air outlet is
regulated by the aps , which are motorized up and
down,and manually moved right and left by the verti-
cal deectors
The condesation removed from the room is drained to the outside.
The air drawn in by the fan enters at the front grill of the
panel and passes through the lter.
Then it passes throught the evaporator coil where
cooled and dehumidied or heated.
It can cool and dehumidify (and heat in models with
heat pump) the air in a completely automatic way.
