MAJOR LINE
Note: this accessory must always be used with a valve control device, to ensure
valve control of the high safety device when the valve is closed (closure of the
condensate drains).
Under operating conditions outside of the recommended temperature and relative
humidity ranges (page Fr-2), the discharge pipe must be insulated to prevent the
formation of condensation, which could damage the installation and the pump. We
recommend the use of a crystal clear translucent PVC pipe with an internal diameter
of 6 mm and an external diameter of 9 mm. The tightness of the connections to the
pump must be verified using a clamp
Fitting the pump, vertical model (fig.12) and horizontal model (fig.13):
If the pump is delivered separately as a kit, screw the pump onto the unit using
the 2 mounts (a) and 2 screws (b), and connect the hose to the condensate pan
(d). Connect a clear drain hose (not supplied) (c) with an interior diameter of 6 mm
between the pump outlet and the wastewater pipe.
Finally, connect the power cables (e) as shown in the diagram supplied with the unit.
Caution: this hose should not be pinched or touch the unit or any other external
component. Wire as indicated on the attached circuit diagram.
ELECTRICAL CONNECTIONS
Major Line
Motor
speed
AC Asynchronous Motor HEE Brushless Motor
102/
104
202/
204
302/
304
402/
404
502/
504
602/
604
102/
104
202/
204
302/
304
402/
404
502/
504
602/
604
Power
input during
operation
(W)
V5 33 58 88 106 108 135 11 25 32 77 90 100
V4 31 41 67 93 94 114 9 15 22 63 80 75
V3 29 36 52 80 79 99 6 11 13 36 42 55
V2 27 31 42 72 72 88 5 8 7 21 26 32
V1 26 27 35 63 63 77 4 5 3 11 13 16
Max. input
current
(A)
V5 0,14 0,25 0,38 0,46 0,47 0,59 0,11 0,20 0,29 0,62 0,71 0,74
V4 0,13 0,18 0,29 0,40 0,41 0,50 0,09 0,13 0,20 0,50 0,62 0,67
V3 0,13 0,16 0,23 0,35 0,34 0,43 0,07 0,11 0,13 0,30 0,35 0,44
V2 0,12 0,13 0,18 0,31 0,31 0,38 0,06 0,09 0,08 0,19 0,21 0,27
V1 0,11 0,12 0,15 0,27 0,27 0,33 0,06 0,06 0,06 0,11 0,13 0,16
The unit must be earthed. CIAT shall not be liable for incidents resulting from
faulty or non-existent earthing. Always follow the circuit diagram delivered
with unit.
● Ensure that the power supply to the unit is disconnected before carrying
out any work.
● Only personnel qualified to perform electrical and maintenance work may
make electrical connections.
As indicated on the data plate, the unit must be connected to a single-phase 230V
power supply (230/1/50Hz-60Hz).
