CIAT PRO-DIALOG+ - Menu Tree Structure

4.8 - Menu tree structure
GENUNIT
TEMP
PRESSURE
SETPOINT
INPUTS
OUTPUTS
PUMPSTAT
RUNTIME
MODES
ALARMS
CONFIG
LOGOUT
ALARMRST CUR_ALRM
ALMHIST1
GENCONF
PUMPCONF
HCCONFIG
RESETCFG
USERCONF
SCHEDULE
HOLIDAY
BRODCAST
DATETIME
DISPLAY
HOLIDY01S
HOLIDY16S HOLIDY02S
…
OCC1P01S OCC1P02S
GENUNIT
TEMP
PRESSURE
SETPOINT*
INPUTS
OUTPUTS
PUMPSTAT
RUNTIME
MODES
ALARMS*
CONFIG
LOGOUT
ALARMRST CUR_ALRM
ALMHIST1
GENCONF
PUMPCONF
HCCONFIG
RESETCFG
USERCONF
SCHEDULE
HOLIDAY
BRODCAST
DATETIME
CTRL_ID
HOLIDY01S
HOLIDY16S HOLIDY02S
…
OCC1P01S
OCC1P02S
NAVIGATION
Password = "0"
ACCESS
ALL
USER
DEFAULT
SCREENS
PASSWORD
General parameters
Temperatures
Pressures
Setpoint
Inputs
Outputs
Pump status
Operating time
Unit status
Alarms menu
Conguration menu
Disconnection
Reset of the alarms
Current alarm
Alarm history
Time schedule
Holidays
General conguration
Pump conguration
Heating/cooling
conguration
Setpoint reset
User conguration
Broadcast
Date and time
Identication control
SHUTDOWN
CONFIRMATION
SCREEN
LIST OF OPERATING
MODES
(for main
interface only)
Schedule 1
Schedule 2
Holidays 1
Holidays 2
Holidays 16
* Congurable from the GENCONF menu
