4.9.5 - INPUTS menu
NAME FORMAT UNIT DESCRIPTION
ONOFF_SW Open/Close - Remote start/stop contact
HC_SW Open/Close - Remote heating/cooling contact
on_ctrl Off, On Cool, On Heat,
On Auto
- Current control
SETP_SW Open/Close - Remote setpoint contact
LIM_SW1 Open/Close - Remote demand limit contact 1
LIM_SW2 Open/Close - Remote demand limit contact 2
FLOW_SW Open/Close - Water flow rate/customer safety loop contact
leak_1_v nn.n Volt Leak detector value 1
leak_2_v nn.n Volt Leak detector value 2
DSHTR_SW Open/Close - Desuperheater user contact
4.9.6 - OUTPUTS menu
NAME FORMAT UNIT DESCRIPTION
CP_A1 On/Off - Compressor output A1
CP_A2 On/Off - Compressor output A2
CP_A3 On/Off - Compressor output A3
fan_a1 0-2 - Fan output A1
fan_a2 0-2 - Fan output A2
exv_a 0-100 % EXV position circuit A
HD_POS_A 0-100 % Position variable fan speed controller A
RV_A On/Off - Four-way refrigerant valve
CP_B1 On/Off - Compressor output B1
CP_B2 On/Off - Compressor output B2
fan_b1 0-2 - Fan output B1
exv_a 0-100 % EXV position circuit B
HD_POS_B 0-100 % Position variable fan speed controller B
RV_B On/Off - Four-way refrigerant valve
C_HEATER On/Off - Heat exchanger and lower coil heater
BOILER On/Off - Boiler output
EHS_STEP 0-4 - Electric heater stages
ALARM On/Off - Alarm relay
RUNNING On/Off - Unit on relay
4.9.7 - PUMPSTAT menu
NAME FORMAT UNIT DESCRIPTION
CPUMP_1 On/Off - Command pump 1
CPUMP_2 On/Off - Command pump 2
ROT_PUMP Yes/No - Pump rotation
WATPRES1 ±nnn.n kPa Water pressure sensor 1
WATPRES2 ±nnn.n kPa Water pressure sensor 2
WP_CALIB Yes/No - Water pressure sensor calibration?
Following a water pressure sensor error, WP_OFFST is deconfigured (-99 kPa) to
inform of the need to calibrate the water loop. This calibration
must be made while
there is no water flow in the machine
WP_OFFST ±nnn.n kPa Water pressure sensor calibration value
DP_FILTR nnn.n kPa Filter pressure drop
WP_MIN nnn.n kPa Minimum water pressure
WAT_FLOW ±nnn.n g/s Water flow rate
CAPPOWER ±nnn.n kW Unit capacity
w_dt_spt nn.n ^C Setpoint delta T
w_dp_spt nn.n kPa Setpoint delta P
drvp_pwr +nnn.n kW Pump capacity
drvp_i +nnn.n A Pump current
drvp_ver xxxxxxxx - Variable pump speed controller version
4 - SETTING UP PRO-DIALOG+ CONTROL
