Cimon Xpanel 4 - Specifications

- 15 -
● XT07
Model CM-XT07CD-AE CM-XT07CD-DE CM-XT07CD-AN CM-XT07CD-DN
LCD Size
7 inch wide
LCD Type TFT color
Colors 65,536 colors
Resolution WVGA 800x480
Backlight LED
Luminance
600 cd/m
2
Backlight Life
50,000 hours
Touch Panel
4 wire resistive
Memory 128 MByte DDR2
Storage 128 MByte SLC NAND Flash
SD Card 1 SD slot None
COM1 RS-232C
COM2 RS-422/485
Ethernet 10/100 BaseT None
USB Host
1 port
Tool Port 1 USB device
Audio 1 port None
Rated Voltage -A: AC 100-240 V / -D: DC 24 V
Power Consumption
6 W
OS Windows CE 6.0
Weight 0.8 kg 0.7 kg 0.8 kg 0.7 kg
Dimension (mm)
185x127x54
Panel Cut (mm) 177x119
Certificate CE, UL (cUL), FCC, IP65
Specification
