- 5 -
Precautions for installation
• Be sure to securely connect all cable connectors to the Xpanel. A loose connection may
cause incorrect input or output.
• Make sure to install the unit vertically.
Precautions for wiring
• Field Ground (FG) wires must be run individually from each unit to the master grounding
terminal. DO NOT daisy chain the FG wires between devices.
• Correctly wire the Xpanel, be sure that the rated voltage and terminal layout are within the
designated range. If the voltage supplied differs from the rated voltage, or incorrect wiring
or grounding is performed, it may cause a fire or unit malfunction and it will void the
warranty.
• Make sure to tighten the screw with standard torque (0.5~0.6Nm). Loose connections may
cause short, fire or malfunction.
• Be careful that metal debris do not enter the Xpanel, they may cause a fire, Xpanel
damage or malfunction.
Precautions for unit disposal
• When this unit is disposed of, it should be done so according to your country’s regulation
for similar types of industrial waste.
CAUTIONS
Essential Safety Precautions
