- 13 -
• Make sure to check if the device’s power and external power supply is turned off before
wiring, via a breaker, or similar unit. Failure to do so may cause electric shock or damage
to the device.
• Since there is no power switch on the Xpanel unit, be sure to attach a breaker- type switch
to its power cord.
•
To avoid a short caused by loose ring terminals, be sure to use ring terminals with an insulating
sleeve.
•
When the FG terminal is connected, be sure the wire is grounded. Not grounding the Xpanel unit
will result in excess noise and vibration.
● Connecting the Xpanel Power Cord
When connecting the power cord, be sure to follow the procedures below.
• Confirm that the Power Cord is unplugged from the power supply.
• Unscrew the screws from the middle three (3) terminals, align the Ring Terminals and
re-attach the screws.
• Confirm that the ring terminal wires are connected correctly.
• The torque required to tighten these screws is 0.678_0.813lbf*ft (0.5 ~ 0.6N•m)
Wiring
WARNING
To Next Page
