● XPANEL Environmental Specification
Item Description
Rated Voltage
DC 24 V or AC 100-240 V
Ambient Temperature
0
℃
–65
℃
Storage Temperature
-20
℃
–65
℃
Ambient Humidity
10%–90% RH (below 29
℃,
no dew condensation)
Storage Humidity
10%–90% RH (below 39
℃,
no dew condensation)
Environment
Condition
800 hPa ~ 1114 hPa (2000 m/6,500 ft or less)
Dust
≤ 0.1 mg/m
3
(Conductive dust is not allowed)
Pollution Degree
≤ Pollution degree 2
Operating Ambience
Free from corrosive gas and excessive dust
Vibration
Resistance
JIS B 3502, IEC/EN 61131-2 compliant
5~9 Hz Single amplitude: 3.5 mm
9~150 Hz Fixed acceleration: 9.8 m/s
2
X,Y,Z directions for 10 cycle (approx. 100 min)
Concussion
Resistance
JIS B 3502, IEC/EN 61131-2 compliant
147 m/s
2
, X,Y,Z directions for ±3 times (Total 18 times)
Noise Resistance Impulse, EFT/Burst, Surge,
±
2 KV, 1 us
Static Discharge
Resistance
Contact Discharge 4 kV (IEC 61000-4-2)
Air Discharge 8 kV (IEC 61000-4-2)
Specification
