CIPU CSPPD704 - Illustrated Parts List; Pump Components Identification

8
ILLUSTRATED PARTS LIST
Ref.No. Part. No. Description QTY Remark
1 647284871 Cover 1
2 65431042080 O-Ring 1
3 647252704 Basket 1
4 647284801 Pump Housing 1
5 647252705 Clip 1
6 65431029080 O-Ring 1
7 65221002000 Screw M5*30 8
8 647284802 Pump Cover 1
9b 647272971000 Impeller For CSPPD704 1
9c 647252771000 Impeller For CSPPD705 1
10 65431044080 O-Ring 1
11 65028003000 Seal Assembly 1
12 647284803 Pump Housing 1
13 647284804 Motor Mounting Plate 1
14 65231016106 Nut M5 8
15d 65023404000 Dual Speed 1.0HP Motor For CSPPD704 1
15e 65023405000 Dual Speed 1.5HP Motor For CSPPD705 1
16 65432002080 Drain Plug Gasket 1
17 648860105 Drain Plug 1
18 647202702 Adaptor 1
19 91382005 1.5’’ Adaptor Assembly 2
