Circor IMO 3E Series User Manual

A
A
SECTION A-A
27
3
1
93
26
92
15
13
12
6
4
11
16
7
8
8
2
USE LOCTITE GASKET
ELIMINATOR #504
ASSEMBLE PUMP SO THAT END
OF IDLER WITH ROOT TAPER IS
AT INLET END OF PUMP
INLET
OUTLET
TORQUE TO
170
u 10 LB IN
TORQUE TO
170
u 10 LB IN
TORQUE TO
40
u 2 LB IN
NOTES:
1. DRAIN HOLE IN COVER IDP #4 TO BE ASSEMBLED
IN THE DOWN POSITION.
FIGURE 6 - IRON CASED C3EB(H)F - FOOT MOUNTED PUMP
