Table 4
LIST OF MATERIALS (FIGURES 3 THROUGH 11)
ITEM PART DESCRIPTION ITEM PART DESCRIPTION
001 Case 036 Tube
002 Inlet Head 036 Lockwashe
003 Packing Box End Cove
037 Space
004 (3) Bolt or Capscrew 038 (1) O-ring (Figure 16)
005 Plug 040 Space
006 (2) Stop Pin 042 (2) Truarc Ring (2)
007 (1) Dyna Seal 043 Retaine
008 (2) Retaining Ring 043 Plug
008 Inboard Cover (Figure 16) 044 (2) Power Roto
009 (1) Gasket (2) 045 Balance Piston Housing
010 (2) Retainer Plate 046 Inboard Cove
011 Capscrew (4) 047 Bolt (4)
012 Spring Pin (2) 048 (2) Space
or Seat Adapte
013 Cotter Pin 049 (1) Ball Bearing
014 Packing Gland Screw (2) 063 (2) Power Roto
014 Spacer (Figure 16) 064 Plug
015 Washer (2) 067 Plug
015 (1) Ball Bearing (Figure 16) 068 Nipple
016 Nut (2) 069 Coupling
016 Bearing Retainer (Figure 16) 070 (1) O-ring (Figure 10)
017 (1) Packing 070 Elbow
017 Bolt (4) Figure 16) 071 Tubing
018 Packing Gland 072 Plug
019 (2) Power Roto
073 Plug
020 (1) Truarc Ring (2) 074 Elbow
021 (2) Idler Rotor (2) 074 Nameplate
022 Oil Balance Tube External 075 O-ring (Figure 10)
022 (2) Balance Piston Housing 075 Plug
023 (2) Idler Balance Piston Housing (2) 075 Nipple
023 Spacer (2) (Figure 16) 076 (1) O-ring
024 (2) Rotor Housing 076 Tee
025 (1) Seal 077 Nipple
026 (2) Oil Balance Tube (2) 078 (2) Check Valve
026 Thrust Plate (Figure 16) 079 Elbow
027 (1) O-ring (4) 080 Elbow
027 Gasket 080 Plug
028 (1) O-ring (2) 081 (1) Gasket
029 (2) Thrust Cage 081 Tubing
029 Bolt (2) (Figure 16) 084 Space
029 Thrust Plate (Figures 18 & 19) 086 (2) Bushing
030 Lockwasher (2) (Figure 16) 090 Space
031 Key 091 Washer (4)
032 (2) Relief Valve 091 Space
033 Nameplate 092 (1) Gasket
034 Drive Screw (2) 092 Spacer (Figure 22)
035 Plug 092 Washer (4)
Quantities are one (1) except when noted in parentheses after description. Items marked (1) are minor kit
items. Items marked (2) are major kit items. This is a General Parts List. Refer to specific rotor size for
appropriate parts that apply specifically to your pump. When an item number applies to more than one part
by noun name, use part as indicated on proper assembly figure for your pump.
