Cirrus SR22T Maintenance Manual

24-30
Page 28
Serials 22-0098 thru 22-1469
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
Figure 24-305
MCU Installation - Serials 22-0098 thru 22-1469 (Sheet 1 of 4)
P111 (REF)
P108 (REF)
P109 (REF)
P115 (REF)
SR22_MM24_2060D
FIREWALL
(REF)
EXTERNAL POWER
RECEPTACLE
(REF)
NOTE
Apply sealant to top corners of MCU, cable exits,
and around external power receptacle.
12
5
11
3
7
10
8
9
3
5
12
13
4
2
3
15
17
1
14
6
3
5
4
4
5
3
6
16
3
T
O
A
L
T
E
R
N
A
T
O
R
1
7. Starter Cable
8. Battery 1 Cable
9. Alternator 1 Cable
10. Alternator 2 Cable
11. Ground Cable
12. Nut
13. MCU Cover
14. J115 Connector
15. J109 Connector
16. J108 Connector
17. J111 Connector
LEGEND
1. Master Control Unit (MCU)
2. Bolt
3. Washer
4. Screw
5. Lock Washer
6. Cable Guide
T
O
A
L
T
E
R
N
A
T
O
R
2
T
O
B
A
T
T
E
R
Y
1
T
O
S
T
A
R
T
E
R
TO GROUND
BUS BAR
ASSEMBLY
T
O
A
L
T
E
R
N
A
T
O
R
2
T
O
B
A
T
T
E
R
Y
1
T
O
S
T
A
R
T
E
R
TO GROUND
BUS BAR
ASSEMBLY
Serials 22-0098 thru 22-1469.

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
