Cirrus SR22T Maintenance Manual

CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
24-30
Page 29
Serials 22-1470 thru 22-1601, 22-1603 thru 22-1643,
22-1645 thru 22-1662
EFFECTIVITY:
Figure 24-306
MCU Installation - Serials 22-1470 thru 22-1601, 22-1603 thru 22-1643, 22-1645 thru 22-1662 (Sheet 2 of 4)
SR22_MM24_2097A
EXTERNAL POWER
RECEPTACLE
(REF)
FIREWALL
(REF)
14. J115 Connector
15. J109 Connector
16. J108 Connector
17. J111 Connector
18. J757 Connector
TO GROUND
BUS BAR
ASSEMBLY
P109 (REF)
P115 (REF)
P108 (REF)
P111 (REF)
15
16
17
18
14
3
3
2
13
12
5
11
3
7
10
9
3
5
12
8
P757 (REF)
LEGEND
1. Master Control Unit (MCU)
2. Bolt
3. Washer
4. Screw
5. Lock Washer
7. Starter Cable
8. Battery 1 Cable
9. Alternator 1 Cable
10. Alternator 2 Cable
11. Ground Cable
12. Nut
13. MCU Cover
4
1
Apply sealant to top corners of MCU
and around external power receptacle.
NOTE
Serials 22-1470 thru 22-1601,
22-1603 thru 22-1643, 22-1645 thru 22-1662.
01 Jan 2012
