Page #47 background imageLoading...
Page #47 background image
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
24-30
Page 47
All
EFFECTIVITY:
R. External Fuse (See Figure 24-307)
MCU 14600-001, 14600-002, 16600-001 & 19900-001: The external fuse, integral to the MCU, is
located on the RH side of the MCU chassis. MCU 19800-001: The external fuse, integral to the MCU,
is located on top of the MCU chassis.
(1) Removal - External Fuse
(a) Set BAT 1, BAT 2, and AVIONICS switches to OFF positions.
(b) Remove engine cowling. (Refer to 71-10)
(c) Remove external fuse from fuse holder assembly.
(2) Installation - External Fuse
(a) Insert external fuse into fuse holder assembly.
(b) Perform Operational Inspection - Master Control Unit. (Refer to 24-30)
(c) Install engine cowling. (Refer to 71-10)
01 Jan 2012

Other manuals for Cirrus SR22T

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cirrus SR22T and is the answer not in the manual?

Cirrus SR22T Specifications

General IconGeneral
ManufacturerCirrus Aircraft
EngineContinental TSIO-550-K
Horsepower315 hp
Max Takeoff Weight3, 600 lbs
Service Ceiling25, 000 ft
Cabin Width49 in
Cabin Height50 in
Seating Capacity4
AvionicsCirrus Perspective+ by Garmin
CategorySingle-engine piston aircraft
PropellerHartzell 3-blade composite
Wingspan38 ft 4 in
Length26 ft
Height8 ft 11 in
Maximum Cruise Speed213 KTAS
Fuel Capacity92 gallons
Stall Speed64 knots
Safety FeaturesCirrus Airframe Parachute System (CAPS)
Cruise Speed183 knots
