Cirrus SR22T Maintenance Manual

24-30
Page 46
All
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
Q. Blade Fuse (See Figure 24-307)
MCU 14600-001, 14600-002, & 16600-001: The blade fuse, integral to the MCU, is located on the
lower LH side of the power board assembly. MCU 19900-001: The blade fuses, integral to the MCU,
are installed in seven locations on the power board assembly. MCU 19800-001: The blade fuses, inte-
gral to the MCU, are installed in 21 locations on the power board assembly.
(1) Removal - Blade Fuse
(a) Set BAT 1, BAT 2, and AVIONICS switches to OFF positions.
(b) Remove engine cowling. (Refer to 71-10)
(c) Disconnect battery 1. (Refer to 24-30)
(d) Remove MCU cover. (Refer to 24-30)
(e) Remove blade fuse from fuse holder.
(2) Installation - Blade Fuse
(a) Insert blade fuse into fuse holder.
(b) Install MCU cover. (Refer to 24-30)
(c) Connect battery 1. (Refer to 24-30)
(d) Perform Operational Inspection - Master Control Unit. (Refer to 24-30)
(e) Install engine cowling. (Refer to 71-10)

Cirrus SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Engine	Continental TSIO-550-K
Horsepower	315 hp
Max Takeoff Weight	3, 600 lbs
Service Ceiling	25, 000 ft
Cabin Width	49 in
Cabin Height	50 in
Seating Capacity	4
Avionics	Cirrus Perspective+ by Garmin
Category	Single-engine piston aircraft
Propeller	Hartzell 3-blade composite
Wingspan	38 ft 4 in
Length	26 ft
Height	8 ft 11 in
Maximum Cruise Speed	213 KTAS
Fuel Capacity	92 gallons
Stall Speed	64 knots
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cruise Speed	183 knots
