Cirrus SR22T Maintenance Manual

24-30
Page 54
Serials 22-1470 thru 22-1601, 22-1603 thru 22-1643,
22-1645 thru 22-1662
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
Figure 24-307
MCU Components - Serials 22-1470 thru 22-1601, 22-1603 thru 22-1643, 22-1645 thru 22-1662 (Sheet 2 of 5)
1
Serials 22-1470 thru 22-1601,
22-1603 thru 22-1643, 22-1645 thru 22-1662.
7
6
25
26
27
SR22_MM24_2101B
LEGEND
1. Master Control Unit ( MCU )
2. Screw
3. ALT 1 Current Sensor
4. ALT 1 Cable Assembly
5. Bolt
6. Washer
7. Nut
8. Midi Fuse
9. ALT 2 Current Sensor
10. ALT 2 Cable Assembly
11. BAT Current Sensor
12. Logic Module
13. Blade Fuse
14. External Fuse
24
24
23
6
2
2
2
21
15
16
14
15. ALT 1 Field
Control Module
16. ALT 2 Field
Control Module
17. Bus Bar, IX A
18. Bus Bar, X
19. Bus Bar, IX C
20. Bus Bar, IX B
21. MCU Cover
22. Spacer
23. Bottom Cover
24. Cable Guide
25. Clamp
26. Loom
27. Cable Tie
20
7
9
7
4
7
6
6
22
12
10
6
17
7
6
7
7
3
6
11
2
5
8
7
6
18
5
13
7
2
6
19
6
2
6
