Cirrus SR22T Maintenance Manual

24-30
Page 56
Serials 22-1602, 22-1644, 22-1663 & subs w/o Per-
spective Avionics
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
Figure 24-307
MCU Components - Serials 22-1602, 22-1644, 22-1663 & subs w/o Perspective Avionics (Sheet 4 of 5)
36
LEGEND
1. Master Control
Unit (MCU)
2. Screw
5. Bolt
6. Washer
7. Nut
8. Midi Fuse
15. ALT 1 Field
Control Module
16. ALT 2 Field
Control Module
22. Spacer
33. Busbar Clamp
34. Busbar 14
35. Busbar 17
36. Busbar 11
37. Busbar 18
38. Busbar 10
39. Current Shunt
40. Insulator
41. Busbar 13
42. Busbar 19
43. Busbar 16
44. Busbar 7
45. Busbar 27
46. Busbar 28
47. Breaker
SR22_MM24_2246C
16
15
2
33
6
7
6
2
Serials 22-1602, 22-1644, 22-1663 thru 22-3025,
22-3026 & subs w/o Perspective Avionics.
37
6
7
38
8
39
6
7
6
8
6
7
42
43
40
2
8
5
6
41
40
39
34
35
2
6
7
46
44
6
39
22
6
7
6
2
8
29
22
5
6
40
6
7
6
7
2
2
47
