Cisco 12000 Series Hardware Troubleshooting Guide

Cisco - Hardware Troubleshooting for Cisco 12000 Series Internet Router Line Card Failures
http://kbase/paws/servlet/ViewFile/15926/hwts_gsrlc_15926.xml?convertPaths=1[8/6/2010 3:56:13 PM]
SLOT 10 : RUN IOS
SLOT 11 : RUN IOS
SLOT 13 : RUN IOS
SLOT 14 : RUN IOS
Table 1 and Table 2 describe the most common types of output that you see from this command and their meanings.
Note: It is possible for the value of the LED to be reversed. For example, IOS RUN can be displayed as RUN IOS.
Table 1 – RP LED Status and Meaning
RP LED
Status
Meaning of LED Status
RP UP
RP is running Cisco IOS software and functioning
correctly
MSTR RP RP is acting as the Primary GRP
SLAV RP RP is acting as the Slave GRP
RP ACTV RP is acting as the Primary GRP
RP SEC RP is acting as the Slave GRP
MEM INIT RP is trying to size the memory
Table 2 – LC LED Status and Meaning
LC LED
Status
Meaning of LED Status
DIAG
DNLD
Line card is downloading Field Diagnostic software
DIAG FAIL Line card has failed Field Diagnostic test
DIAG
