Cisco 1830 Series - DC Power Cable Routing Illustration

17
Figure 4 Routing the DC Power Cable
1
Kensington lock slot
4
DC power cable plugged into the 48VDC
port
2
Power cable routed through the strain relief
retention clips
5
AP secured using a padlock
3
DC power cable
353859
1
2
3
4 5
