3-40
Cisco Video Surveillance 2500 Series IP Camera User Guide
OL-19273-02
Chapter 3 Configuring and Managing the IP Camera
Status Windows
Network Window
The Network window displays information about various IP camera network settings and operations.
You configure the settings as described in the
“Basic Setup Window” section on page 3-5 and the
“Wireless Setup Window” section on page 3-7.
To display the Network window, access the configuration windows as described in the Accessing the IP
Camera Windows” section on page 2-6, click Status, then click Network.
To make sure that the Network window shows the most current information, click the Refresh button.
Table 3-24 describes the options in the Network window. All options are for display only.
Ta b l e 3-23 Audio/Video Window Options
Option Description
MPEG-4 Settings 1
Resolution Image size of the primary video stream.
Image Quality Image quality of the primary video stream.
Frame Rate Frame rate of the primary video stream.
MPEG-4 Settings 2
Note These options appear if the Resolution setting for MPEG-4 Settings 1 in the Video window is
lower than 720 x 480 for NTSC or 720 x 576 for PAL.
Resolution Image size of the second video stream.
Image Quality Image quality of the second video stream.
Frame Rate Frame rate of the second video stream.
Audio Setting
Note This option appears if you configured the Enable Audio option in the Audio window.
Audio Setting Displays the audio setting that is configured for the IP camera.
Ta b l e 3-24 Network Window Options
Option Description
Network
Network Type Type of network in use.
Connection Speed Wired model only. Speed and type of the camera connection to the network.
IP Address IP address of the IP camera.
Subnet Mask Subnet mask that is associated with the IP address of the IP camera.
Gateway IP address of the remote gateway that is used by the IP camera.
Primary DNS IP address of the primary Domain Name Server (DNS).
Secondary DNS IP address of the secondary DNS.
Wireless
Note These options apply to the wireless IP camera only.
SSID Wireless SSID.
